88 Series 3 High Efficiency Commercial Gas Oil Boiler

  • 88-series-3.jpg

Available For Order Now!



Cast Iron Section Heat Exchanger

  • Time-proven, horizontal section design
  • Wide, open waterways that are more forgiving of older boiler plant water systems

Ease of Installation & Service

  • Knock-Down, assembled block or fully packaged shipment options
  • Job-site assembly enables fit into tight boiler room applications

Reliable, Long-Life Peace-of-Mind Operation

  • Robust, heavy-duty design offers extended service life
  • Weil-Mclain reliability as the market leading cast iron boiler provider



Technical Data
Downloads

Technical Data

Model Burner Capacity Gross Output Net Ratings Efficiency Ratings Boiler H.P. Flue Outlet Diameter Boiler Water Content Approx. Boiler Weight
Input Oil (GPH) Input Gas (MBH) Output Oil (MBH) Output Gas (MBH) Output Oil (MBH) Output Gas (MBH) Oil Gas HP Inches Gal Lbs
Combustion Efficiency Thermal Efficiency Combustion Efficiency Thermal Efficiency
488 6.9 960 840 806 731 701 --- 87.0% --- 84.0% 23.8 10 109 2,860
588 9.1 1280 1108 1075 964 935 --- 87.0% --- 84.0% 31.7 10 132 3,340
688 11.4 1600 1389 1344 1207 1169 --- 87.0% --- 84.0% 39.7 12 155 3,820
788 13.8 1920 1681 1613 1462 1402 --- 87.0% --- 84.0% 47.6 12 178 4,345
888 16.0 2240 1949 1882 1695 1636 --- 87.0% --- 84.0% 55.6 14 201 4,925
988 18.2 2560 2242 2176 1950 1892 88.0% --- 85.0% --- 63.5 14 224 5,600
1088 20.5 2880 2526 2448 2169 2129 88.0% --- 85.0% --- 71.4 14 247 6,130
1188 23.0 3200 2834 2720 2464 2365 88.0% --- 85.0% --- 79.4 16 270 6,695
1288 25.0 3520 3080 2992 2678 2602 88.0% --- 85.0% --- 87.3 16 293 7,260
1388 27.5 3840 3388 3264 2946 2838 88.0% --- 85.0% --- 95.2 16 316 7,890
1488 29.5 4160 3634 3536 3160 3075 88.0% --- 85.0% --- 103.2 18 339 8,410
1588 32.0 4480 3942 3808 3428 3311 88.0% --- 85.0% --- 111.1 18 362 9,005
1688 34.5 4800 4250 4080 3696 3548 88.0% --- 85.0% --- 119.0 18 385 9,525
1788 36.5 5120 4497 4352 3910 3784 88.0% --- 85.0% --- 127.0 18 408 9,780
1888 39.0 5440 4805 4624 4178 4021 88.0% --- 85.0% --- 134.9 20 431 10,775
